68.4V AI Aircraft smart Battery 18S 5C 30000mAh with software BMS，with pluggable interface and cycle life more than 650 times, is widely used in drone fields such as plant protection, surveying and mapping, logistics, and electricity.
68.4V AI Aircraft smart Battery 18S 5C 30000mAh with software BMS
|
No.
|
Item
|
General Parameter
|
Remark
|
|
1.1
|
Description
|
68.4V AI Aircraft smart Battery 18S 5C 30000mAh with software BMS | |
|
1.2
|
Cell Model
|
3.8v 30000mAh
|
|
|
1.3
|
Typical Capacity
|
30Ah
|
|
|
1.4
|
Typical Voltage
|
68.4V |
|
|
1.5
|
End of Charge Voltage
|
78.3V
|
|
|
1.6
|
Charge Current
|
0.5C 15A
|
|
|
1.7
|
Charging time
|
2-3 Hours
|
|
|
1.8
|
End discharge Voltage
|
54V
|
|
|
1.9
|
Max continuous charge current
|
3C(recommend 2C)
|
|
|
2.0
|
Maximum Continuous Discharging Current
|
240A |
|
|
2.1
|
Maximum pulse discharge current
|
300A
|
|
|
2.2
|
Over-Current Discharge Protection
|
YES |
|
|
2.3
|
Short circuit protection
|
YES
|
|
|
2.4
|
Weight
|
13.2kgs
|
|
|
2.5
|
Cycle life
|
≥650 |
|
|
2.6
|
Operation Temperature Range
|
Charge 0~50 ℃, Discharge -20~60 ℃
|
1.Light: headlamp, emergency light, solar flashlight, searchlight, lanten, bicycle light, LED light, military
flashlight, high-end flashlight, high power flashlight, bright flashlight.
2.Outdoor sports products: camping light, mountain bike light, solar emergency light, self-defense flashlight,
3.Consumer electronics: MPS, Tablet PC. laptop, Bluetooth earphone, power bank, portable DVD player,
speaker, microphone, sound equipment, audio, Digital camera
4.Home appliances products: electric mop, electric vacuum cleaner, electric children toys, electric shoes,
electric blanket.
5.Medical devices
6.Instruments and meters: water meter, gas meter.
7.Electric transportation vehicles: electric bike, electric car, e-scooter, electric motor, electric trolley, electric cart.
8.Power tools: electric drill, mower
9.UPS, backup energy, storage energy.
We warmly welcome OEM design inquiry! We could make customized battery pack specially for you!
1.Long life cycle, large capacity and good shock resistance
2.Low self-discharge and good discharge performance at low temperature
3.Strong charging acceptance and quick-charging capability
4.Strong over-discharge resistance and charge retention
5.Maintenance-free and no acid or water for maintenance in usage
6.Excellent large current discharge performance, and have obvious advantages in startup and climbing
7. High temperature performance
8. Environmental friendly
9. Lighter weight smaller size
10.Most safe no explosion no fire
